Modernus

• Minimal extrusions

• Front set glass/Coplaner

• Options for single and dual-glazed framing

• Supported glass thicknesses:

• 3/8”, 1/2”, 5/8”; tempered & laminated

• Supported door types: Swing and Sliding doors

• Frameless Glass | Aluminum Framed | Wood Doors (swing only)

• Lead time: 5 to 6 weeks for stocked options, 8 to 10 weeks for non-standard product

• Standard Trim Height: 1-1/2”

• Standard Trim Depth: 2-3/8” for single glazed, 3-1/8” for dual-glazed

• Standard Max Vertical Height: 10’-0”

• Can seamlessly combine single and dual-glazed framing options

• Butt seamed glass-to-glass VHB connections.

• Standard 3-way return condition with polycarbonate channel

• Drywall Endcaps - Flybys

• True & Applied Mullions

• Based on thickness & type of glazing installed

• With dual-glazed up to 49 STC

• Stock Colors: clear and black anodized

• Additional color options: a wide variety of anodized finishes | painted and real wood-wrapped veneer options available
